1.1.5 General Product Features
The general product features cover performance features and the technical prerequisites
for installation and operation of your device.
The features are summarised in the following table:
General Product Features
Property bintec RS353j , bintec RS353jw and bintec
RS353j-4G
Dimensions and weights:
Equipment dimensions without cable (B x
H x D):
240 mm x 42 mm x 180 mm
Weight approx. 1,100 g
Transport weight (incl. documentation,
cables, packaging)
approx. 1600 g
Memory
128 MB RAM,
32 MB Flash-ROM
LEDs 18 (1x Power, 1x Status, 5x2 Ethernet, 6x Function)
Power consumption of the device 4.7 Watt
Voltage supply AC 100 bis 240 V, 50 bis 60 Hz
Environmental requirements:
Storage temperature -25 °C to +70 °C
Operating temperature 0 °C to +40 °C
Relative atmospheric humidity 10 % to 95 % (non-condensing)
Room classification Only use in dry rooms.
Available interfaces:
Ethernet IEEE 802.3 LAN (4-port switch) Permanently installed (twisted pair only), 10/100/1000
mbps, autosensing, Auto MDIX
Gigabit LAN/WAN Port Permanently installed (twisted pair only), 10/100/1000
mbps, autosensing, Auto MDIX
VDSL/ADSL Internal VDSL/ADSL modem for Annex B and Annex J
ISDN BRI Port Permanently installed
USB Port USB2.0 type A
USB Console (Type B) Supported Baud rates: 1200-115200 (default: 115200
Baud)
Standards & Guidelines
R&TTE Directive 1999/5/EC
1 Installation bintec elmeg GmbH
8 bintec RS Series
