Access data Example value Your values
Password *+%
Wireless LAN (optional)
You can operate your device as an access point and therefore connect individual work sta-
tions (e.g. laptops, PCs with wireless card or wireless adapter) by wireless connections to
your local network via WLAN (Wireless LAN) and let them communicate with each other.
The table "Data for the Wireless LAN configuration" shows the information required.
As data can be transmitted over the air in the WLAN, this data can in theory be intercepted
and read by any attacker with the appropriate resources. Particular attention must therefore
be paid to protecting the wireless connection.
Note the following:
• Follow the safety precautions when configuring your WLAN.
• Please also read Sicherheit im Funk-LAN [Security in Wireless LAN] published by the
Federal Office for Information Security, see http://www.bsi.de.
Data for the Wireless LAN configuration
Access data Example value Your values
Preshared key for WPA2-PSK without default
Installation location of your system (
Channel to be used for WLAN 
Network name (SSID) for your
WLAN
without default
Visibility of the SSID in the wireless
network
 "1
Security setting 23 4
2.3.2 Configuring a PC
In order to reach your device via the GUI and to be able to carry out configuration, the PC
used for the configuration has to satisfy some prerequisites.
Have the device assign an IP address to your PC as follows:
(1) Click the Windows Start button and then Settings -> Control Panel -> Network Con-
nections (Windows XP) or Control Panel -> Network and Sharing Center->
Change Adapter Settings (Windows 7).
(2) Click on LAN Connection.
bintec elmeg GmbH
2 Basic configuration
bintec RS Series 29
