Field Description
You must configure a proxy for each destination port to which
VoIP clients from the LAN can connect. An error message ap-
pears when you enter multiple ports (e.g. 5060; 5061).
The ports can be provider-specific.
Possible values are to &.
The default value is .
Prioritize SIP Calls
Select whether you want to prioritise SIP Calls.
The function is enabled with "1.
The function is disabled by default.
16.2 RTSP
In this menu, you configure the use of the RealTime Streaming protocol (RTSP).
RTSP is a network protocol for controlling multimedia traffic flows in IP-based networks.
Payload data is not transferred using RTSP. Rather, it is used to control a multimedia ses-
sion between sender and recipient.
If you want to use RTSP, the firewall and NAT must be configured accordingly. In the VoIP-
>RTSP menu, you can activate the RTSP proxy to enable requested RTSP sessions over
the defined port if required.
16.2.1 RTSP Proxy
In the VoIP->RTSP->RTSP Proxy menu, you configure the use of the RealTime Streaming
protocol.
Fig. 163: VoIP->RTSP->RTSP Proxy
16 VoIP bintec elmeg GmbH
438 bintec RS Series
