Field Description
• ) (default value): RIP is not enabled.
• A E: Enables sending and receiving of version 1 RIP
packets.
• A E: Enables sending and receiving of version 2 RIP
packets.
• A E/E:Enables sending and receiving RIP packets of
both version 1 and 2.
• A E *##: RIP V1 messages are sent, received
and processed as per RFC 2091 (triggered RIP).
• A E *##: RIP V2 messages are sent, received
and processed as per RFC 2091 (triggered RIP).
Route Announce Select this option if you want to set the time at which any activ-
ated routing protocols (e.g. RIP) are to propagate the IP routes
defined for this interface.
Note: This setting does not affect the interface-specific RIP con-
figuration mentioned above.
Possible values:
• .+  5 (not for LAN interfaces, interfaces in Bridge
mode and interfaces for leased lines): Routes are propagated
if the interface status is up or ready.
• .+ 1( (default value): Routes are only propagated if the
interface status is up.
• 317(: Routes are always propagated independently of op-
erational status.
11.1.2 RIP Filter
In this menu, you can specify exactly which routes are to be exported or imported.
You can use the following strategies for this:
• You explicitly deactivate the import or export of certain routes. The import or export of all
other routes that are not listed is still allowed.
• You explicitly activate the import or export of certain routes. In this case, you must also
explicitly deactivate the import or export of all other routes. This is achieved using a filter
for IP Address / Netmask = no entry (this corresponds to IP address 0.0.0.0 with net-
mask 0.0.0.0). To make sure this filter is used last, it must be placed at the lowest posi-
11 Routing Protocols bintec elmeg GmbH
288 bintec RS Series
