Fig. 198: Local Services->HotSpot Gateway->HotSpot Gateway->
The Local Services->HotSpot Gateway->HotSpot Gateway-> menu consists of the
following fields:
Fields in the menu Basic Parameters
Field Description
Interface
Choose the interface to which the Hotspot LAN or WLAN is con-
nected. When operating over LAN, enter the Ethernet interface
here (e. g. en1-0). If operating over WLAN, the WLAN interface
to which the access point is connected must be selected.
Caution
For security reasons you cannot configure your device over
an interface that is configured for the Hotspot. Therefore
take care when selecting the interface you want to use for
the Hotspot.
If you select the interface over which the current configura-
tion session is running, the current connection will be lost.
You must then log in again over a reachable interface that
is not configured for the Hotspot to configure your device.
17 Local Services bintec elmeg GmbH
520 bintec RS Series
