Patient Monitor User’s Manual
1-10
1.3.3 ECG Waveform Display Mode
Fig 1-6 ECG Display Mode
1. HR parameter area: The values shown in the area are
current HR value and its higher and lower alarm limits.
2. ECG
waveform display area: Waveform shown in the area
is current ECG waveform.
1
2
