Patient Monitor User’s Manual
10
Resp bandwidth(BW) 0.25~2.0Hz(-3dB)
Measurement range 0~150 rpm
The high/low limit can be
adjusted continuously
Resolution 1 rpm
Accuracy ±2 rpm or ±2%
A.7.3 BLTSpO2
SpO
2
Measurement
range
0~100%
Resolution 1%
Accuracy 70~100%：± 2%
Alarm Select the high and low alarm limit of
SpO
2
Sensor Pulse oximetry sensors contain LEDs
that emit red light at a wavelength of
approximately 660 nm and infrared light
at a wavelength of approximately 905
nm.
The total optical output power of the
