Patient Monitor User’s Manual
9
Response of
HR to QRS
amplitude is
1mVp-p,
width is 10ms
Adult: without response
Alarm range
0 bpm to 300 bpm, high/low limit can be
adjusted continuously.
A.7.2 RESP Specifications
RESP
Method Impedance
Measuring lead Lead I(RA-LA)、
II(RA-LL)optional， II(default)
Excitation frequency 64.8 kHz sine wave
Excitation voltage ≤0.3mA@64.8 kHz
Measuring impedance
range
0.2 ~3Ω
Base line impedance
range
500~2000Ω(using defibrillation
cable with 1Ω)
Gain X0.25、X1、X2
