Instruction Manual TProfessional Basic 06/2011 15
4.3 The TProfessional Basic control panel
Start
Stop
Navigation
LED
Block
Status
Back
Keypad
Menu Buttons
Soft Keys
Start
Stop
Navigation
LED
Block
Status
Back
Keypad
Menu Buttons
Soft Keys
Start
Stop
Navigation
LED
Block
Status
Back
Keypad
Start
Stop
Navigation
LED
Block
Status
Back
Keypad
Menu Buttons
Soft Keys
4.4 High Performance Smart Lid (HPSL)
To achieve optimum pressure on the tubes the TProfessional Basic is equipped with a height
adjustable heated lid.
Close the lid:
After the samples have been placed in the block close the lid. Turn the wheel clockwise until
you hear a clicking noise. In this mode the pressure will not increase further, even when you
keep on turning the wheel.
Note: The pressure of the lid has been optimized for a fully loaded block. If only very few tubes
are loaded to the block you should place two dummy tubes each in the four corner positions to
avoid damage of tubes by excessive pressure.
Open the lid:
First: Release pressure by turning the wheel counter clockwise. As soon as there is no more
resistance the pressure has been released.
Then: Open the lid with by pushing the front button.
