Appendix 1 SiteHawk Analyzer default Settings
Description Default Setting
Touchstone Data Format RI - Real-Imaginary
Allocation of Channels 1
Active Channel Number 1
Marker Value Identification Capacity
(Stimulus)
8 digits
Marker Value Identification Capacity
(Response)
5 digits
Vertical Divisions 10
Traces per Channel 1
Active Trace Number 1
Number of Sweep Points 201
Stimulus Start Frequency 1 MHz
Stimulus Stop Frequency 6 GHz
Stimulus IF Bandwidth 1 kHz
Sweep Range Setting Start / Stop
Trigger Mode Continuous
Table of Calibration Coefficients Empty
Error Correction ON
Trace Scale 10 dB/division
Reference Level Value 0 dB
Reference Level Position 5 Div
Phase Offset 0°
Trace Display Format Return Loss (dB)
Maximum Distance 1.49 m
Time Domain Kaiser Window Normal
Number of Markers 0
