BK Precision 9115/B - Preliminary Check; Self-Test Errors

13
Table 2.2 - Wire Gauge Rating
AWG
6
8
10
12
14
16
18
20
22
Imax(A)
75
55
40
25
20
13
10
7
5
mΩ/meter
1.3
2.1
3.3
5.2
8.3
13.2
21
33.5
52.8
2.3 Preliminary Check
Complete the following steps to verify that the power supply is ready for use.
1. Verify AC Input Voltage
Verify and check to make sure proper AC voltages are available to power the instrument.
The AC voltage range must meet the acceptable specification as explained in “2.1 Input
Power and Fuse Requirements”.
2. Connect Power and Self-Test
Connect AC power cord to the AC receptacle in the rear panel and press the power
switch to the |(ON) position to turn ON the instrument. It will run through a self-test
procedure with the screen shown in below:
Self-test Errors
The following errors will be displayed if self-test did not complete successfully:
Error Message on Display
Description
EEPROM FAILURE
The internal EEPROM is corrupted or damaged.
Config Data Lost
The last operation data within the EEPROM is lost.
Calibration Data Lost
Calibration data within the EEPROM is lost.
FactoryCal.Data Lost
Factory calibration data is lost.
MainframeInitialize Lost
The system settings within the EEPROM is lost.
If any of these errors occur, please contact B&K Precision.
System Selftest . . . .
. .
