6 Specifications
Note: All specifications apply to the unit after a temperature stabilization time of 15 minutes over an ambient
temperature range of 23 °C ± 5 °C. Specifications are subject to change without notice.
Environmental Conditions:
This power supply is designed for indoor use and operated with maximum relative humidity of 95%.
Model
9115/B / 9115/B-AT
9116/B
9117
Output Rating
Voltage
0 – 80 V
0 – 150 V
0 – 80 V
Current
0 – 60 A
0 – 30 A
0 – 120 A
Max Output Power
1200 W
1200 W
3000 W
Load Regulation
(1) (2)
Voltage
0.01 % + 5 mV
0.05 % + 30 mV
0.05 % + 30 mV
Current
0.1 % + 10 mA
0.1 % + 30 mA
0.1 % + 30 mA
Line Regulation
(2)
Voltage
0.02 % + 1 mV
0.02 % + 20 mV
0.02 % + 20 mV
Current
0.02 % + 1 mA
0.02 % + 10 mA
0.02 % + 10 mA
Programming/Readback Resolution
Voltage
1 mV
3 mV
2 mV
Current
1 mA
1 mA
3 mA
Programming/Readback Accuracy
(2)
Voltage
0.02 % + 30 mV
0.05 % + 30 mV
0.05 % + 30 mV
Current
0.1 % + 60 mA
0.2 % + 30 mA
0.2 % + 120 mA
Ripple (20 Hz – 20 MHz )
Voltage
≤ 60 mVpp
≤ 60 mVpp
≤ 80 mVpp
Current
100 mArms
40 mArms
120 mArms
Temperature Coefficient
(0 °C – 40 °C)
(2)
Voltage
0.02 % + 30 mV
Current
0.05 % + 10 mA
Readback Temperature Coefficient
(0 °C – 40 °C)
(2)
Voltage
0.02 % + 30 mV
Current
0.05 % + 5 mA
Efficiency
73% (120 VAC)
75% (220 VAC)
75% (120 VAC)
80% (220 VAC)
80% (220 VAC)
Power Factor (full load)
0.99
0.99
0.987
Input Current (nominal)
13.8 A @ 120 VAC
7.3 A @ 220 VAC
13.3A @ 120 VAC
6.9 A @ 220 VAC
17.1 A @ 220 VAC
AC Input
115/230 VAC ± 10 %,
47 Hz – 63 Hz
115/230 VAC ± 10 %,
47 Hz – 63 Hz
220 VAC ± 10 %,
47 Hz – 63 Hz
Standard Interface
USBTMC, GPIB(non-B MODELS ONLY), RS-232, RS-485, Ethernet
(3)
Dimensions (WxHxD) (mm)
414.5 x 44.5 x 483.2
414.5 x 44.5 x 483.2
436.5 x 89.3 x 532
Weight
8.5 kg
8.5 kg
17 kg
Operating Temperature
0 °C – 40 °C
Storage Temperature
-20 °C – 70 °C
(1)
With remote sense connected
(2)
Accuracy specified as ±(% of output + offset) after a temperature stabilization time of 15 minutes over an
ambient temperature range of 23 ºC ±5 ºC
(3)
For model 9117 only
