8.45in(W) x 3.8in(H) x 13.9in(D)
*) LVP: Limit Voltage Protection. Limits the voltage than can be set either via the front panel or remote control command.
NOTE: Specifications and information are subject to change without notice. Please visit www.bkprecision.com
for the most
current product information.
3.2 Supplemental Characteristics
State Storage Memory
50 user-configurable stored states
Recommended Calibration Interval
1 year
AC Input Ratings (selectable via switch on the rear panel)
220AV±10%，47～63Hz
110AV±10%，47～63Hz
Maximum power consumption
Model 9130
Power 750VA
Cooling
Fan cooled
Operating Temperature
0 to 40 °C for max rated output
Storage Temperature
-20 to 70 °C for storage environment.
Environmental Conditions
Designed for indoor use in an installation category II, pollution degree 2 environment. Designed to operate at
maximum relative humidity of 95% and at altitudes of up to 2000 meters.
