1) Terminal block for GND reference and additional negative output terminal
2) AC receptacle
3) Ventilation holes
4) Interface connector for remote control of power supply
5) 110V/220V AC Power selection switch
6) Fuse compartment
2.2 Preliminary Checkout
The following steps will help you verify that the power supply is ready for use.
1
．Check the list of supplied items
Verify that you have received the following items with your power supply. If anything is missing, contact your
authorized B+K Precision distributor.
• Power cord
• Instruction manual
• Calibration Report
• Communication cable
