1. Introduction
Description
The 9130 is a fully programmable triple Output DC Power Supply delivering 0-30V/0-3A on 2
outputs and 0-5V/0-3A on 1 output. Each output is fully floating and outputs can be adjusted
independently or connected in series or parallel to produce higher voltages or currents. The front
panel keys and the control knob provide a convenient means to adjust the voltage and current of a
selected output; enable or disable parallel or series tracking mode; store and recall operating states
or enable/disable individual outputs. The 9130 is ideally suited for applications in Electronic Test,
Production and Service, where multiple independent DC supplies are required and bench space is
at a premium.
Key Features
3 independent, fully programmable and electrically isolated outputs
Series or parallel operation
Display Voltage and Current for of all 3 channels simultaneously
Over Current (OCP) and Over Temperature (OHT) protection
Very compact foot print ( 2U x 1/2)
Bright and easy to read display (VFD technology)
High resolution, accuracy and stability
Output on/off control
Low ripple and low noise
SCPI compatible command set, communicate via USB or RS232 port
Application Software for front panel emulation and simple test sequence generation
50 memory locations for instrument state storage & recall
Convenient data entry via knob or numerical key pad
Rack mount kit available
