BK Precision 9130

44
1
2
3
4
5
6
7
8
9
10
11
1
Configure the software operating parameters and serial communication parameters.
2
Voltage chart
3
Voltage and current displayed for all 3 channels
4
Set the voltage value
5
Set operation mode: PC Control or Panel Control
6
Set the output state: Output On/Output Off
7
“Local Enable” allows the user to use the front panel keys while the instrument is in remote control mode.
When “Local Disable” is active, the front panel keys of the instrument are disabled.
8
Set the current value
9
Status bar: Displays the power supply model, communication status and operation status.
10
Set voltage and current value quickly and conveniently via predefined hotkeys
11
Current chart
