SPECIFICATIONS
Model
4053B
4054B
4055B
Channels
2
Frequency Characteristics
Sine & Square
1 µHz – 10 MHz
1 µHz – 30 MHz
1 µHz – 60 MHz
Triangle, Ramp
1 µHz – 500 kHz
Pulse
1 µHz – 12.5 MHz
Noise (-3 dB)
> 60 MHz
Arbitrary
1 µHz – 6 MHz
Accuracy
± 25 ppm (1 year)
Resolution
1 µHz
Arbitrary Characteristics
Built-in Waveforms
196 built-in waveforms (includes DC)
Waveform Length
16k points / Ch
Vertical Resolution
14 bits
Sampling Rate
150 MSa/s
Minimum Rise/Fall
Time
6.5 ns (typical)
Jitter (pk-pk)
8 ns (typical)
Non-volatile Memory Storage
> 1000 16k points waveforms (100 MB in file system)
Output Characteristics
Amplitude Range
2 mVpp – 10 Vpp into 50 Ω (4 mVpp – 20 Vpp into open circuit), ≤10 MHz
2 mVpp – 5 Vpp into 50 Ω (4 mVpp – 10 Vpp into open circuit), > 10 MHz
Amplitude Resolution
up to 4 digits
Amplitude Accuracy
(10 kHz sine)
± (1 % + 1 mVpp)
Amplitude Flatness
± 0.3 dB (reference 10 kHz, 2.5 Vpp, 50 Ω oad )
Cross Talk
< -60 dBc (both channels set to 0 dBm, sine 50 Ω load)
Offset Range (DC)
± 5 V into 50 Ω (± 0 V into open circuit)
Offset Resolution
up to 4 digits
Offset Accuracy
± ( |offset setting value| x 1% + 3 mV)
Channel Output
Impedance
50 Ω, high impedance
Output Protection
Short-circuit protection
Waveform Characteristics (sine, square, triangle, ramp)
Harmonic Distortion
(Sine)
DC – 10 MHz, < - 60 dBc / 10 MHz – 30 MHz < -50 dBc / 30 MHz – 60 MHz,
< - 40 dBc (0 dBm input signal)
