Burst Trigger Source
The burst trigger source can be internal, external or manual. The generator will generate a
burst output when a trigger signal is received and wait for the next trigger source.
To configure the Trigger Source, once in the Burst menu:
Internal Trigger
1. Press the Source softkey.
2. Press the Internal softkey.
3. The generator outputs a continuous burst waveform when internal trigger is selected.
4. Go to the second page of this menu, press Trig Out and select “Up” or “Down” and the
[Aux In/Out] connector at the rear panel will output a trigger signal with specified edge
or set it “Off” to not output a signal from the [Aux In/Out].
External Trigger
1. Press the Source softkey.
2. Pres the External softkey.
3. The generator accepts the trigger signal input from the [Aux In/Out] connector at the
rear panel when external trigger is selected. A burst will be generated on a CMOS pulse
with specified polarity. To set the CMOS pulse polarity go to the second page of this
menu, and press Edge and select “Up” or “Down”.
Manual Trigger
1. Press the Source softkey.
2. Pres the External softkey.
3. Press the Trigger softkey to generate a burst.
To Next Page
