BK Precision BK4053B User Manual

69
Set to Default
Sets the unit to defaults settings:
a. Press the Utility button.
b. Press the System softkey.
c. Press the Set to Default to set the system to the default setting. The default settings
of the system are:
Setting
Default value
Output
Function
Sine Wave
Frequency
1 kHz
Amplitude/Offset
4 Vpp/0 Vdc
Phase
0°
Load
High Z
Modulation
Carrier
1 kHz Sine Wave
Modulating
100 Hz Sine Wave
AM Depth
100％
FM Deviation
100 Hz
ASK Key Frequency
100 Hz
FSK Key Frequency
100 Hz
FSK Hop Frequency
1 MHz
PSK Key Frequency
10 0Hz
PM Phase Deviation
100°
PWM Width Dev
190 μs
Sweep
Start/Stop Frequency
500 Hz/1.5 kHz
Sweep Time
1 s
Trig Out
Off
Mode
Linear
Table 22 - Factory Default Settings
