Output Check
Follow the steps below to do a quick check of the settings and waveform output.
1. Turn on the instrument and set the instrument to default settings. To set to default,
press Utility → System → Set To Default to set the system to the default setting. The
instrument will set both channels with the following parameters:
Output
Default
Function
Sine Wave
Frequency
1 kHz
Amplitude/Offset
4 Vpp/0 Vdc
Phase
0°
Load
High Z
Modulation
Default
Carrier
1 kHz Sine wave
Modulating
100 Hz Sine wave
AM Depth
100%
FM Deviation
100 Hz
ASK Key Frequency
100 Hz
FSK Key Frequency
100 Hz
FSK Hop Frequency
1 MHz
PSK Key Frequency
10 0Hz
PM Phase Deviation
100°
PWM Width Dev
190 μs
Sweep
Default
Start/Stop Frequency
500 Hz/1.5 kHz
Sweep Time
1 s
Trig Out
Off
Mode
Linear
Direction
↑
Burst
Default
Burst Period
10 ms
