Changing Settings on the SuperUser Display
4. Open the door so that the door is in the first step open position and then touch
Press when door open.
5. Look at the Threshold and Actual values.
•• The Threshold value displays the value that marks the shift between
status door open and the status door closed.
•• The Actual value displays the actual input from the sensor. The actual
value must be greater than 10 when the door is closed.
6. Verify that a green checkmark is displayed next to Press when door closed and
Press when door open. If the values are not acceptable, the display shows Door
sensor error. See Troubleshooting on page 22 for more information.
7. Touch Done to end the calibration process.
If the door has not been calibrated, a warning is displayed asking if you
want to exit anyway.
Note If the oven has both a front and a back door, you calibrate the sensor of
the back door by touching Calibrate back door. You then go through the same
steps as described above.
Logs and Statistics
You can use the logs and statistics to see which processes failed and when they failed.
Fault Log
The Fault log displays the latest thirty errors in a list with the most recent error on top.
1. On the SuperUser display, touch Logs and statistics, and then touch
Fault log. The fault log is displayed.
SERVICE MANUAL 19
