Blodgett DFG-100 Replacement Parts List

OCTOBER 16, 2007 19 DFG-100/200
INTERIOR COMPONENTS & EXTERIOR VIEW
32232
Motor, 1 SP
or
32291
Motor, 2 SP
6
4342
Lamp, 120V
3
20758
Interior Baffe, Porc
or
20864
Interior Baffle, S/S
1
15853
Blower Wheel
2
19081
Rack Supports
DFG100
or
21422
Rack Supports
DFG200
4
18768 or 4701
Racks DFG100
or
20246
Racks DFG200
NOTE: See
Text for part
number.
Requires Serial
Number.
8
Liner Bottom
See Text
7
18799
Burner Assy, Units after 01/86
or
19097
Burner Assy
Units before 01/86
1
34541
Bodytop, Units after
01/05/99
or
17399
Bodytop, Units before
01/05/99
10
90027
Motor Mount
& Panel Assy
5
Combustion
Compartment
Cover
NOTE: See
Text for part
number.
Requires Serial
Number.
13
NOTE: The liner baffle looks
like the back of the oven.
34570
Bodyside, RH
11
34570
Bodyside, LH
11
21134
Axial Fans,
Qty 2
14
SEE PAGE 18 & 19 FOR
EXPLODED VIEW OF BURNERS.
90036
15
16815
