Blodgett DFG-100 Replacement Parts List

OCTOBER 16, 2007 26 DFG-100/200
Ref. Part
No. No. Description
AFTER JULY, 1984
 20806 Door Assy. Sld, LH
 20805 Door Assy., Sid RH
1  20804 Door Assy. w/ Gls, LH
2  20803 Door Assy. w/ Gls, RH
BETWEEN JANUARY, 1983 & JULY, 1984
 20169 Door Assy. Sld, LH
 20805 Door Assy. Sld, RH
 20170 Door Assy. w/ Gls, LH
 20803 Door Assy. w/ Gls, RH
NOTE: Replacement Doors for Ovens Prior to 1/83
are no longer available
3 9035 Window Tool, for installation and removal of
window assy
11 9036 Window Assy., Drop In (10-1/8" x 17-1/8")
(After 1/83)
11867 Window Assy., Drop In (20-1/2" x 14-1/4")
(Before 1/83)
6 17558 Door Handle, Porc. (After 6/84)
7 18081 Top Plate, Door Handle (After 6/84)
17403 Wooden Door Handle
(Between 1/83 & 7/84)
20358 Grip, for Wooden Door Handle
(Between 1/83 & 7/84)
15754 Door Handle, 14" (Before 1/83)
8583 Door Catch, Striker Plate (Before 1/83)
8584 Door Catch, Ball Plunger (Before 1/83)
5742 Key, Spanner (Before 1/83)
16 90017 Washers, Door (Set of 2)
14 90004 Bushings, Door Hinge (Set of 2)
15 16657 Sleeve, Upper Door Bushing
8 17557 Hinge Pin, Upper Door
13 35702 Microswitch & Bracket Assy., Door
Replaces 19978, Units after 07/84
13 35918 Microswitch Assy., Door
Replaces 19978, Units before 07/84
5 17311 Center Trim, Door (After 1/83)
4 16448 Pressure Lock (After 1/83)
90037 Gasket Assy., Center (Before 1/83)
12 17519 Gasket Assy., Perimeter (Between 7/84 and
12/01/2005)
36876 Gasket Ass'y,Perimeter (After 12/01/2005)
90010 Gasket Assy., Perimeter (Before 7/84)
90009 Arm, Lower Door w/Hinge Pin (Before 1/83)
9 20359 Arm Assy., Door LH (After 7/84)
90075 Arm Assy., Door LH (Before 7/84)
10 90076 Arm Assy., Door RH
DOOR COMPONENTS
NOTE: SEE PAGE 24 & 25 FOR
LOWER DOOR SUPPORTS.

Blodgett DFG-100 Specifications

General

Brand	Blodgett
Model	DFG-100
Category	Convection Oven
Language	English
