OCTOBER 16, 2007 28 DFG-100/200
LOWER DOOR SUPPORT COMPONENTS
Ref. Part
No. No. Description
1 36037 Lower Door Support Assy w/Microswitch
Units after 10/06/00 or SN 100600RA018T
2 20659 Lower Door Support Assy
Units between 7/84 and 10/06/00 or SN 100600RA018T
3 90072 Lower Door Support Assy
Units between 1/83 & 7/84
4 90060 Lower Door Support Assy
Units before 1/83
16487 Washer, Neoprene (Qty 4) mounts to door support for switch
NOTE: Lower Door Support Assy includes the hinge pins, arms,
chain & turnbuckles, sprocket assys, cam assy, and microswitch.
5 35702 Microswitch & Bracket Assy, Door
Replaces 19978 Units after 07/84
6 35918 Microswitch Assy., Door
Replaces 19978 Units before 07/84
35419 Bracket, for Microswitch
Units after 07/84
6195 Bracket, for Microswitch
Units before 07/84
7 90076 Arm Assy, w/Hinge Pin RH
Units after 01/83
8 20359 Arm Assy, w/Hinge Pin & Bracket LH
Units after 07/84
9 90075 Arm Assy, w/Hinge Pin & Bracket LH
Units between 01/83 and 07/84
10 90009 Arm Assy, w/Hinge Pin LH or RH
Units before 01/83
NOTE: IF YOU NEED TO REPLACE THE SPROCKETS, CHAIN & TURNBUCKLE, OR THE
HINGE PIN WE STRONGLY SUGGEST ORDERING THE ENTIRE LOWER DOOR SUPPORT.
IT WILL INCLUDE ALL OF THESE COMPONENTS AND WILL GREATLY REDUCE YOUR
LABOR COSTS AND TIME INVESTED.
NOTE: SEE PAGE 22 & 23 FOR
DOOR COMPONENTS
