Blodgett DFG-100 Replacement Parts List

OCTOBER 16, 2007 32 DFG-100/200
EXCLUSIVE TO BOSTON
MARKET
Ref. Part
No. No. Description
33171 Blower Wheel
18587 Relay & Bracket, 3PDT 120V
19619 Rocker Switch, DPST, Black
19620 Rocker Switch, DPST, Black
23077 Capacitor & Bracket, Electrolytic, 2SP
20738 Combustion Cover Assy.
20757 Access Panel Assy.
31274 Transformer 120V to 24V
33073 Relay Board
33074 Probe, RTD 1000 OHM
33132 Control Cover
EXCLUSIVE TO EXPORT
Ref. Part
No. No. Description
32506 Thru Pipe Assy. CE
24 M9182 Valve, Gas CE & Australia
34530 Pilot Burner & Ignitor Assy., Nat CE
34531 Pilot Burner & Ignitor Assy., LP CE
32525 Tube, Pilot CE
34974 Conversion Kit, Air Pressure Differential
Switch (Replaces M3330) CE
Before 01/20/99 or S.N. 012099RA033S
M9422 Air Pressure Differential Switch, switch only
CE
M9705 PolyurethaneTubing, (Per Foot, Total 3 feet)
used w/pressure switch CE
36066 Thermostat, High Limit Kit (Manual reset) CE
Replaces M3295
32543 Pressure Tap, Inlet CE
M2841 Fitting, Pressure Tap CE
34906 Manifold Assy (w/pressure tap) CE
26 M3168 Spark Box, 240V (Landis & Gyr) CE
27 M6449 Filter, Noise CE
15637 Lamp, 230/250V, 50 Watt CE
4922 Socket, Lamp CE
16037 Indicator Light, 250V, Red, Round CE
16537 Indicator Light, 250V, Amber, Round CE
18267 Indicator Light, 250V, Blue, Round CE
18439 Potentiometer, Humidiare Control CE
20350 Buzzer, 240V CE
M3172 Timer, Fixed, 2 Second CE
20084 Timer, 60 Min., 240V, 50 HZ CE
18319 Timer, Adjustable, 240V CE
24684 Knob, Mode CE
24685 Knob, Adjust TNT CE
30517 Rocker Switch, DPST, Matte Black CE
21430 Axial Fan, 230V, 34 CFM 3" CE
32501 Decal, Infinite CE
32489 Decal, SSD CE
32494 Decal, Infinite w/ Humidaire CE
32502 Harness, Infinite Control CE
32488 Harness, SSD Control CE
32502 Harness, Infinite Control w/ Humidaire CE
18366 Harness, Steam Injection CE
35152 Harness & Socket Assy 15 AMP NON CE
35153 Harness & Socket Assy 15 AMP CE
35157 Harness, Rear Control CE
18366 Harness, Steam Injection CE
34811 Control Access Cover (DFG 100 only) CE
32232 Motor, 1SP
20356 Transformer, 115/230 to 24V
EXCLUSIVE TO ARBY'S WITH
MEAT PROBES
Ref. Part
No. No. Description
37131 Control, Meat Probe
37134 Probe, Meat (qty 8)
37130 Bracket, Meat Probe
37135 Probe, Temperature Meat Probe
37116 Harness, control meat probe
37119 Grommet, Rubber Hi Temp
36446 Relay, SPST 24 VDC
36628 Relay, DPST 25A 208/240 V
37132 Manifold, meat probe
37133 Harness, manifold meat probe
37126 Tube, meat probe harness
37509 Manifold Assy (includes:
Probe, harness, manifold, tube, and grommet.)
36616 Knob, Control
20348 Spark Module
18868 Switch, Rotary 3 Position
30662 Kit, momentary light switch
