SECTION 6
PARTS LIST
SINGLE OVEN EXPLODED VIEW
ITEM QTY PART NO. DESCRIPTION
1 1 48382 UPPER LH END PLUG ASSEMBLY
2 1 48387 LOWER LH END PLUG ASSEMBLY
3 1 48408 LOWER RH END PLUG ASSEMBLY
4 1 48412 UPPER RH END PLUG ASSEMBLY
5 1 48378 EYEBROW, UPPER LH END PLUG ASSEMBLY
6 1 48410 EYEBROW, UPPER RH END PLUG ASSEMBLY
7 4 51398 END PLUG MOUNTING BRACKET ASSEMBLY .875
8 8 21296-0005 SCREW, HEX HEAD, WSHHD 12-14X3/4 SS BSD
9 6 36452 NUT, WING-PLASTIC 1/4-20
10 4 3101908 LEG, 4” ADJ FT (NPS)
11 1 48395 BOTTOM TRAY ASSEMBLY
12 1 48396 COVER, TOP
13 4 51387 SCR, MS, SLT TRHD 8-32X1/2 18-8
14 1 M10434 CORDSET, 40 AMP 250V 2P 3W
15 1 16469 NAMEPLATE, BLODGETT SM
16 1 52256 COVER, CHAIN
