45
ENGLISH
SECTION 6
PARTS LIST
BLOWER ASSEMBLY
T
EM
Q
T
Y
PART NO.
DESCRIPTION
1
1
28021-0061
SWITCH, MOMENTARY-1OA, NO 2 POLE
2
2
30927
BUMPER, WINDOW
3
1
51399
FAN, COOLING, 230V AC, 295 CFM
4
2
52244
MOTOR, BLOWER, CW, 208/230 50/60HZ
4a
2
57284
MOTOR, BLOWER, CW (ONLY)
5
2
57258
PLATE, AIR VENT
6
4
7007413
SCR, SHOULDER 10-32X, 34 18-8
50
52
Table of Contents
Table of Contents
5
Model Identification
7
S1820 Electrical Specifications
8
Air Fingers and Blank Plates - See Figure 1-9
10
Blower Fan
10
Conveyor Motor and Conveyor Belt
10
Cooling Fan
10
Electric Heaters
10
II. Component Function
10
Component Function
10
Section 2 I. Unloading
13
Installation Kit
14
Parts List for Series S1820 Electric Oven
14
S1820 Oven Installation Required Kits and Equipment
14
Circuit Breaker
18
Electrical Rating
18
Electrical Specifications
18
Suggested
18
Supply Wire
18
Utility Rough-In Dimensions and Positioning for S1820 Ovens
18
Unloading
13
II. Ventilation Guidelines
18
Ventilation Guidelines
18
Electric Supply for Electric-Heated Ovens
18
Electrical Connection Information for S1820 Ovens
19
Section 3 Installation
19
Control Functions
21
Component Information and Location
22
Door Safety Switch
22
Blower Switch
22
Heat Switch
22
Temperature Controller
22
Conveyor
23
Measuring Conveyor Speed
23
Step-By-Step Operation
24
Startup Procedures
24
Daily Startup
24
Power Failure
24
Shutdown Procedure
24
Normal Operation - Step-By-Step
26
A.daily Startup Procedure
26
Daily Shutdown Procedure
26
Quick Reference: Troubleshooting
28
Section 4 Maintenance
29
Maintenance - Daily
30
Exterior
30
Cooling Fan
30
Conveyor Belt
30
Crumb Pans
30
Maintenance - Monthly
31
II. Maintenance - Monthly
31
Removing Conveyor from Oven for Cleaning
31
Air Fingers Disassembly for Cleaning
33
Reassembly of Air Fingers
34
Reinstall End Plugs
36
Checking Conveyor Belt Tension
37
Conveyor Reassembly into Oven
37
Conveyor Belt Link Removal
38
Attaching Drive Chain
39
Maintenance - Every 3 Months
40
Electrical Terminals
40
Ventilation
40
Maintenance - Every 6 Months
40
S1820 Electric Oven Key Spare Parts
41
Key Spare Parts Kit
41
Section 5 Troubleshooting
43
Troubleshooting Charts
43
Section 6 - Parts List
47
Single Oven Exploded View
47
Relay Panel
49
Blower Assembly
51
Control Panel
53
Single Conveyor
55
Section 7 Electrical Schematics
57
Wiring Diagram, E208-240V 50/60/1, S1820
57
Wiring Diagram, E380-480V 50/60/1, S1820
58
Wiring Diagram, E230-240V CE S1820
59
Wiring Diagram, E380-400V CE S1820
60
