49
ENGLISH
SECTION 6
PARTS LIST
SINGLE CONVEYOR
ITEM OTY PART NO. DESCRIPTION
1 1 48471 WELDMENT
2 4 M4817 BEARING, RULON
3 1 M4815 SHAFT, DRIVE
4 1 51408 SHAFT, IDLER
5 10 M4818 SPROCKET, WIRE BELT
6 1 M7471 BELT, WIRE, STN STL
7 1 50060 LINK, MASTER LEFT 1/2P-18”
8 1 50062 LINK, MASTER CENTER 1/2P-18”
9 1 50061 LINK, MASTER RIGHT 1/2-18
10 1 55567 ASSY, CHAIN HIGH SPEED
11 1 55217 SPROCKET, CHAIN #25-20T-1/2
12 1 45349 SPROCKET, 25B25 w/5/16 BORE
13 1 3002757 MOTOR, CONVEYOR DRIVE
14 1 50163 KIT, CONVEYOR PICK-UP
15 1 51297 EXTENSION, CONVEYOR 6
16 1 51296 EXTENSION, CONVEYOR 12
17 2 48469 PAN, CRUMB
18 2 51409 PAN, CRUMB VENTED
