Installation
14
Electrical Connection
Wiring diagrams are located in the control
compartment and on the back of the oven.
This oven is supplied for connection to 115 volt
grounded circuits. The electric motor, indicator
lights and related switches are connected through
the 6’ electric supply cord found at the rear of the
oven.
WARNING!!
This appliance is equipped with three
pronggroundingtypeplugforyour
protection against shock hazard and
should be plugged directly into a properly
grounded three prong receptacle. DO
NOT cut or remove the grounding prong
from this plug.
THE BLODGETT OVEN COMPANY CANNOT AS-
SUME RESPONSIBILITY FOR LOSS OR DAMAGE
SUFFERED AS A RESULT OF IMPROPER INSTAL-
LA TION.
ELECTRICAL SPECIFICATIONS
Model Hz Volts Phase Amps Electrical Connection
(minimum size)
U.S. and Canadian Installations
SHO-G 60 115 1 6 Cord set provided
General Export Installations
SHO-G 50 220-240 1 3 Size per local code
To Next Page
