Julius Blum GmbH, Industriestr. 1, A-6973 Höchst herewith declare on our own responsibility that the product MINIPRESS (M53.
xxxx) with drilling heads (MZK.1000, MZK.1900, MZK.8000, MZK.8800) to which this Declaration refers, complies with the following
EU Directives:
EC Machine Directive 2006/42/EC
EC EMV Directive 2004/108/EC
The following harmonised European standards have been used to ensure proper implementation of the requirements specified in the
EU Directives:
EN ISO 12100-1, EN ISO 12100-2, EN 60204-1, EN 349, EN 983
In addition, the following standards have also been applied:
EN ISO 11202, EN ISO 11204, DIN 33893-2
Registered location:
Section wood
Testing and certification centre in BG - PRÜFZERT
Postfach 800480
70504 Stuttgart
GS testing certification no.: 051140
BG testing certification no.: 051141
Hoechst, 06.07.09 Documentation authorised agent:
Dipl.-Ing. Herbert Blum, Dipl.-Ing. (FH) Thomas Maier,
Managing Director www.blum.com
www.blum.com
F.1 - EC Declaration of Conformity
F - EC Declaration of Conformity / Techn. Data
F.2 - Technical data
1) General data
• Voltage: see serial tag
• Current: see serial tag
• Connected load
Motor: 1.1 kW
• RPM: see serial tag
• Air consumption: 1.5 litres
• Noise emission: 80.4 dB(A)
Important: Provide a 7 A mains backup fuse.
Installation location:
• Temperature range: 5 - 40 °C (39.2 - 104 °F)
• Rel. humidity: 35 - 55 %
3) Max. work piece thickness
• drilling only 45 mm
• Insertion
Depending on the fitting max. 20 mm to max. 32 mm
5) Max. drilling diameter
• Max. drilling diameter 45 mm
• For drill bits see BLUM complete catalogue
Only Blum-approved drill bits
may be used.
2) Weight and measurements
Weight: m= 47 kg
Dimensions: H= 771 mm
W= 684 mm
D= 690 mm
4) Max. drilling distance
• Drilling distance centre spindle: 0 - 70 mm
6) Accessories
• For accessories see BLUM complete catalogue
