MFP112 USER MANUAL
13
contact support@blustream.co.uk / support@blustream.com.au
Matrix
Switcher
Adjusting the video output resolution
The MFP112 has an in-built video scaler allowing you to alter the resolution of the video output.
When in ‘Splitter mode’ both the HDMI outputs (output 1) and HDBaseT (output 2) can be processed via the video scaler, allowing you to
alter the resolution of both outputs. (*Note - This is subject to turning on/o the scaler using the ‘Bypass’ command - see page 17 for further
details).
When in ‘Matrix Switcher’ mode only the HDBaseT output (output 2) can be processed via the video scaler. The HDMI output (output 1) is
a straight pass-through video signal with no video scaling . HDMI output 1 has access to the HDBaseT input and 4x HDMI inputs only when
in this mode. (*Note - HDBaseT output 2 can bypass the video scaler when selecting the HDBaseT or HDMI 1-4 inputs using the ‘Bypass’
command - see page 17 for further details).
Changing the output video resolution
The MFP112 video output resolution can altered in 3 ways:
1 Front panel control - Press the ‘FORMAT’ button to scroll through output resolutions
2 MFP112 remote control
1
3 Using Blustream RS-232/Telnet commands - Please see page 17 for detailed commands
The MFP112 remote control has fixed output video resolutions. To change the resolution
simply select the required video format required.
