MFP112 USER MANUAL
14
www.blustream.co.uk
EDID Control
EDID (Extended Display Identification Data) is a data structure that is used between a display and a source. This data is used by the source to
find out what audio and video resolutions are supported by the display then from this information the source will determine what the best
resolution is to output.
While the objective of EDID is to make connecting a digital display to a source a simple plug and play procedure issues do arise when
multiple displays or video matrix switching is introduced because of the increased number of variables.
By pre-determining the video resolution and audio format of the source and display device you can potentially work around compatibility
issues associated with some display and source combinations.
1 Using EDID dip-switches on the rear panel of the unit. Please see table below for settings.
Note: You must power-cycle the switcher aer changes have been made in order for the EDID
settings to update.
2 Using Matrix Front Panel Buttons
a. Press MENU button
b. Panel will display ‘EDID settings’. Press SELECT button
c. Select the input you wish to fix the EDID on or select ‘All’. Use UP/DOWN buttons to toggle selection and SELECT button to confirm
d. Select video resolution required (4K, 1080p, 3D etc). Use UP/DOWN buttons to toggle selection and SELECT button to confirm
e. Select audio format required (2.0, 5.1, 7.1). Use UP/DOWN buttons to toggle selection and SELECT button to confirm
The EDID configuration can be altered in 2 ways:
EDID Dip-switch settings:
NOTE: If the source selected is a VGA input the switcher will automatically output the best resolution possible.
[DIP]=0000: HDMI 1080p@60Hz, Audio 2CH PCM
[DIP]=0001: HDMI 1080p@60Hz, Audio 5.1CH PCM/DTS/Dolby
[DIP]=0010: HDMI 1080p@60Hz, Audio 7.1CH PCM/DTS/Dolby/HD
[DIP]=0011: HDMI 1080i@60Hz, Audio 2CH PCM
[DIP]=0100: HDMI 1080i@60Hz, Audio 5.1CH PCM/DTS/Dolby
[DIP]=0101: HDMI 1080i@60Hz, Audio 7.1CH PCM/DTS/Dolby/HD
[DIP]=0110: HDMI 1080p 3D@60Hz, Audio 2CH PCM
[DIP]=0111: HDMI 1080p 3D@60Hz, Audio 5.1CH PCM/DTS/Dolby
[DIP]=1000: HDMI 1080p 3D@60Hz, Audio 7.1CH PCM/DTS/Dolby/HD
[DIP]=1001: HDMI 4K@30Hz, Audio 2CH PCM
[DIP]=1010: HDMI 4K@30Hz, Audio 5.1CH PCM/DTS/Dolby
[DIP]=1011: HDMI 4K@30Hz, Audio 7.1CH PCM/DTS/Dolby/HD
[DIP]=1100: DVI 1280x1024, Audio 2CH PCM
[DIP]=1101: DVI 1920x1080, Audio 5.1CH PCM/DTS/Dolby
[DIP]=1110: DVI 1920x1200, Audio 7.1CH PCM/DTS/Dolby/HD
[DIP]=1111: HDMI EDID copy (EDID copied from HDMI output 2 display)
