MFP112 USER MANUAL
03
contact support@blustream.co.uk / support@blustream.com.au
Our MFP112 is a multi-format presentation switcher with in-built video scaling, audio
embedding, audio de-embedding, EDID management and HDBaseT connectivity.
The MFP112 works in 2 modes - as an 11 input dual output switcher or as a 2 output matrix.
With control of the switcher using the front-panel push buttons, IR remote control, TCP/IP
or RS-232 interface it is an ideal solution for commercial installations.
Introduction
FEATURES:
• MFP112 Switcher can function in 2 modes:-
Splitter mode - Both HDMI output 1 & HDBaseT
output 2 display the same selected input.
Matrix Switcher mode - HDMI/HDBaseT inputs are
independently switchable to HDMI output 1
& HDBaseT output 2.
HDMI output 1 has access to HDBaseT input + HDMI
inputs 1-4 ONLY (HDMI signal pass-through including
4K 30 Hz resolution).
HDBaseT output 2 is a scaled and formatted output
(user configured) that has access to all HDMI,
HDBaseT and Analogue video inputs with associated
audio.
• Built-in video scaling, both up-scaling (maximum of 1080p)
and down-scaling capabilities (including 4K 30Hz to lower
resolutions).
• HDBaseT output (output 2) for distribution of
video sources up to 100m distance (4K up to 70m)
with bi-directional IR & RS-232 and LAN serving (*HDBaseT
Receiver sold separately)
• HDBaseT input for integration of remote HDMI source
up to 100m distance (4K up to 70m) with bi-directional IR &
RS-232 & LAN serving (*HDBaseT Transmitter sold
separately)
• Video inputs support all industry standard video
resolutions including VGA-WUXGA and 480i-4K where
applicable.
• Scaled video output resolutions include 720p, 1080P,
1280x1024, 1024x768, 1360x768, 1440x900 & 1680x1050.
• Audio embedding - Independent Analogue L/R audio input
can be embedded to HDMI/HDBaseT outputs + Analogue
L/R audio and Coaxial digital outputs concurrently (Feature
available on HDMI/HDBaseT outputs 1 + 2 in Splitter mode
and HDBaseT output 2 only in Matrix Switcher mode).
• HDMI audio breakout to Analogue L/R audio and Coaxial
digital outputs concurrently (linked to HDBaseT output
2 when in Matrix Switcher mode). Note: input must be 2ch
PCM for Analogue audio output to work, does not downmix 5.1ch
audio signals.
• Volume control of HDMI, Analogue L/R audio and Coaxial
digital outputs.
• Supports all known HDMI audio formats on HDMI pass-
through, including Dolby TrueHD, Dolby Atmos, Dolby
Digital Plus and DTS-HD Master Audio transmission.
• Front panel display for status feedback.
• Control via front panel, IR and RS-232.
• 3rd Party drivers available for all major home control
brands.
• Advanced EDID management.
• HDCP compliant.
