MFP112 USER MANUAL
16
www.blustream.co.uk
Video Input Connectors: 4x HDMI Type A, 1x HDBaseT RJ45, 4x VGA, 1x Component (YPbPr), 1x Composite
Video Output Connectors: 1x HDMI Type A, 1x HDBaseT RJ45
Audio Input Connectors: 11x 3.5mm Analogue audio stereo jack
Audio Output Connectors: 1x 3.5mm Analogue audio stereo jack, 1x SPDIF Coaxial digital
RS-232 serial port: 1x DB 9 connector (Switcher control), 1x 3-pin Phoenix connector for RS-232 pass-through to HDBT RX/TX
IR Input ports: 2x 3.5mm stereo jack
IR Output ports: 1x 3.5mm mono jack
Casing Dimensions (W x H x D): 438mm x 225mm x 45mm, without feet
Dimensions including connections (W x H x D): 438mm x 235mm x 45mm
Shipping Weight: 1.5Kg
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature : -4°F to 140°F (-20°C to 60°C)
Power Supply: DC 12V/5A
Package Contents:
• 1x MFP112
• 1x 12V/5A power supply
• 1x Remote control
• 4x IR Receivers
• 3x IR Emitters
• 1x IR control cable - 3.5mm-3.5mm cable
• 1x Serial cable - 9-pin RS-232 to 3-pin phoenix connector
• 1x 1U rack mount kit
• 1x User manual
Maintenance
Clean this unit with a so, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
Specifications:
