MFP112 USER MANUAL
15
contact support@blustream.co.uk / support@blustream.com.au
Example Schematic
MFP112
Control
Processor
MFP112
4x Analogue audio L/R inputs (for
embedding to associated HDMI inputs)
VCR
MAXIMUM 4 SOURCES
REMOTE SOURCE
1 2 3 4
(Zone 1 HDMI)
DISPLAY
(Zone 2 HDBaseT)
DISPLAY
HDMI Loop Out
HEX100ARC-Tx
Transmitter
HEX100ARC-Rx
Optical In HDMI Out Ethernet 1 Ethernet 2 Ethernet 3
Receiver
MENU
3:30
-0:49
9 of 13
Video
RS232
HDMI
Coaxial Digital
VGA
Cat 5/6
Analogue L/R Audio
IR Cable
