MFP112 USER MANUAL
02
www.blustream.co.uk
Features 03
Panel Descriptions
04/05
MFP112 Control Ports
06
Remote Control Descriptions
07
HDBaseT Receiver Options
08
HDBaseT Transmitter Options
09
Terminating HDBaseT CAT Cable 10
Understanding HDBaseT Status Lights 10
IR Distribution
11
Switcher Front Panel Display
12
Adjusting The Video Output Resolution 13
EDID Configuration
14
Application Diagram
15
Specifications
16
Package Contents
16
Maintenance
16
RS-232 Commands
17/18
Infrared Commands
19/20
Contents
Thank you for purchasing
this product.
For optimum performance and safety,
please read these instructions care-
fully before connecting, operating or
adjusting this product. Please keep this
manual for future reference.
Surge protection device
recommended
This product contains sensitive electri-
cal components that may be damaged
by electrical spikes, surges, electric
shock, lightning strikes, etc. Use of
surge protection systems is highly
recommended in order to protect and
extend the life of your equipment.
Safety And
Performance Notice
The transmission distances of HDMI
over UTP cables are measured using TE
CONNECTIVITY 1427071-6
EIA/TIA-568-B termination (T568B) of
cables is recommended for optimal
performance.
To minimize interference of the un-
shielded twisted pairs in the CAT5e/6
cable do not run the HDBaseT /
Cat5e/6/6a cabling with or in close par-
allel proximity to mains power cables.
Do not substitute or use any other
power supply other than the enclosed
unit, or a Blustream approved replace-
ment.
Do not disassemble Blustream hard-
ware for any reason. Doing so will void
the manufacturer’s warranty.
To Next Page
