BMC 3B Luna G3 APAP User Manual

Luna
®
G3 APAP / Luna
®
G3 CPAP User Manual V1.0
12 / 48
Air Outlet
DC Inlet
Filter Cap (Air Inlet)
Heated Tubing Port
Fig. 10-2
Name
Function
Air Outlet
Deliver pressurized air; connect to the tubing
Heated Tubing Port
Connected to the plug of the heated tubing
DC Inlet
An inlet for the DC power supply
Filter Cap (Air Inlet)
Cover and secure the air filter, which is used to filter dust
and pollen in the air entering the device
Transfer Box
SD Card Slot
Fig. 10-3
Name
Function
Transfer Box
For the connection of the device to the water chamber
SD Card Slot
Insert the SD card into this slot
CAUTION!
• The pictures in this manual are only for reference, if they are different from the
material object, the latter shall prevail.
