BMC Roadmachine

Detailed assembly instructions
41
Roadmachine Owners Manual
4 6 Nm
Threadlocker
• Tighten to 6 Nm using a hex 4mm wrench.
• For Roadmachine 01 and Roadmachine option A: ICS full integrated, route the front brake hose
alonside the flat steerer.
Follow the table instruction to place the hose on the appropriate side of the steerer tube.
Standard setup
front brake = left hand
UK setup
front brake = right hand
ICS Cockpits
right
drive side
left
non drive side
ICS Stems
left
non drive side
right
drive side
i
INFORMATION: Crossing brake hose (cable routing) in an ICS cockpit is preferable. It will allow
an easier installation and smoother steering.
• Hold the brake hose on the flat steerer by wrapping with electrical tape.
routing on the
left / non-drive side
L R L R
routing on the
right / drive side
