5. Apply Loctite to the brake pivot thread and bolt it onto the fork.
6. Repeat steps 1 – 4 for the second brake arm.
Note to use the dark spring for the left side brake arm.
7. Cut a comfortable length of Shimano brake cable housing and run it through the top cap and the fork hinge.
8. Cut the brake cable housing 30mm from the top cap and install the cable adjusters.
Please refer to the official Shimano installation instructions.
9. Run the front brake cable thru the housing.
30mm
8
