BMW E36 - Pin Assignments (X8500)

2460.2Ća
1998
Pin Assignments
04/99
BM
BMW
BMWBMW
E = Input, A = Output, M = Ground
X8500
Pin Type Description/Function Connection
177 Not used
178 A Shift-lock solenoid control Shift-lock
179 Not used
180 A Band solenoid Transmission valve unit (318is)
4 A Solenoid valve 3 control (–) Transmission valve unit (328i)
181 A Hydraulic pressure regulator control (–) Transmission valve unit
182 M Ground Ground point (318is)
183 Not used
184 E Gear range signal L2 Automatic transmission range switch
185 E Gear range signal L4 Automatic transmission range switch
186 E Brake pedal position Brake light switch
187 Not used
188 E Sport mode signal Not used
189 E Manual mode signal Program switch
190 E Output speed (–) Transmission valve unit
191 M Ground for shield Shield for speed sensor
192 Not used
193 A S-program indication Not used
194 E Kick-down signal Kick-down switch
195 E ASC signal ASC module (328i)
196 E Automatic mode signal Program switch
197 E Oil temperature signal (–) Transmission valve unit
198 E Oil temperature signal (+) Transmission valve unit
199 Not used
200 Not used
201 A Fault indicator signal Instrument cluster
202 E Battery voltage B+ jump start junction point
203 A M-program indication Program switch
204 M Ground Ground point
205 Not used
