Pin Assignments
04/99
BM
BMW
BMWBMW
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
206 A Solenoid valve 1 control (–) Transmission valve unit
207 Not used
208 A Torque converter clutch solenoid valve
control (–)
Transmission valve unit
209 A Solenoid valve 2 control (–) Transmission valve unit
210 M Ground Ground point
211 Not used
212 E Gear range signal L1 Automatic transmission range switch
213 E Gear range signal L3 Automatic transmission range switch
214 Not used
215 Not used
216 E RPM speed signal TD Engine control module (318is)
217 Not used
218 E Output speed (+) Transmission valve unit
219 Not used
220 Not used
221 A A-program indication Program switch
222 E A/C compressor-ON-signal Engine control module (318is)
223 Not used
224 E Brake switch test signal Brake light switch
225 Not used
226 Not used
227 Not used
228 A Voltage supply Shift-lock/Transmission valve unit (318is)
52 A Voltage supply Shift-lock (328i)
229 E Voltage pressure regulator Transmission valve unit
230 E Voltage supply, terminal 87 Engine control module relay
231 E Voltage supply, terminal 87 Engine control module relay (318is)
232 Not used
233 E Cruise control signal Cruise control module
234 Not used
235 Not used
