BMW E36 - Page 124

2460.2Ćc
1998
Pin Assignments
04/99
BM
BMW
BMWBMW
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
236 E Programming voltage Data link connector
237 Not used
238 Not used
239 Not used
240 Not used
241 Not used
242 Not used
243 Not used
244 Not used
245 Not used
246 Not used
247 Not used
248 Not used
249 Not used
250 Not used
251 Not used
252 Not used
253 Not used
254 Not used
255 Not used
256 Not used
257 Not used
258 E/A Jumper plug (328i)
259 E/A Jumper plug (328i)
260 Not used
261 E/A Can-Low Engine control module
262 E/A Can-High Engine control module
263 A RxD diagnostic data link Data link connector (318is)
264 E/A TxD diagnostic data link Data link connector
