BMW E36 - Pin Assignments (X7000)

BMW
BMW
BMWBMW
2460.4Ća
1998
Pin Assignments
04/99
E = Input, A = Output, M = Ground
X7000
Pin Type Description/Function Connection
1 Not used
2 A Shift-lock Shift-lock
3 A Solenoid valve 5 Transmission valve unit
4 A Torque converter clutch solenoid valve Transmission valve unit
5 A Hydraulic pressure regulator Transmission valve unit
6 Not used
7 Not used
8 Gear range signal L2 Automatic transmission range switch
9 Gear range signal L4 Automatic transmission range switch
10 E Brake pedal position Brake light switch
11 Not used
12 E S-program indication Program switch
13 E M-program indication Program switch
14 E Speed sensor Transmission valve unit
15 M Shield speed sensor Shield
16 A Speed sensor n-turbine Transmission valve unit
17 E S-program Program switch
18 E Kick-down signal Kick-down switch
19 E ASC signal ASC module
20 E E-program Program switch
21 M Ground oil temperature sensor Transmission valve unit
22 E Oil temperature sensor Transmission valve unit
23 M Shield speed sensor Shield
24 Not used
25 A Fault indicator signal Instrument cluster
26 E Battery voltage Jump start junction point
27 E M-program Program switch
28 M Ground, electronics Ground point
29 Not used
30 A Solenoid valve 1 Transmission valve unit
