Pin Assignments
04/99
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
31 A Solenoid valve 4 Transmission valve unit
32 A Solenoid valve 3 Transmission valve unit
33 A Solenoid valve 2 Transmission valve unit
34 M Ground Ground point
35 Not used
36 E Gear range signal L1 Automatic transmission range switch
37 E Gear range signal L3 Automatic transmission range switch
38 Not used
39 Not used
40 Not used
41 Not used
42 A Speed sensor n ab (+) Transmission valve unit
43 Not used
44 E Speed sensor n-turbine Transmission valve unit
45 E E-program indication Program switch
46 Not used
47 Not used
48 E Brake switch test signal Brake light switch
49 Not used
50 Not used
51 Not used
52 A Voltage supply Shift-lock
53 A Voltage supply for solenoid valves Transmission valve unit
54 E Voltage supply DME relay
55 Not used
56 Not used
57 E Cruise control signal Cruise control module
58 Not used
59 Not used
60 E Programming voltage Data link connector
61 Not used
62 Not used
