BMW E36 - Page 136

BMW
BMW
BMWBMW
2460.4Ćc
1998
Pin Assignments
04/99
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
63 Not used
64 Not used
65 Not used
66 Not used
67 Not used
68 Not used
69 Not used
70 Not used
71 Not used
72 Not used
73 Not used
74 Not used
75 Not used
76 Not used
77 Not used
78 Not used
79 Not used
80 Not used
81 Not used
82 E/A Jumper plug
83 E/A Jumper plug
84 Not used
85 E/A CAN-LOW Engine control module
86 E/A CAN-HIGH Engine control module
87 Not used
88 E/A TxD diagnostic data link Data link connector
