3450.1bĆa
1998
Pin Assignments (318is)
04/99
BM
BMW
BMWBMW
E = Input, A = Output, M = Ground
X1170
Pin Type Description/Function Connection
56 A Right rear inlet valve ABS hydraulic unit
57 A Separator valve ABS hydraulic unit
58 M Ground Ground point
59 E Voltage supply Fuse 21
60 Not used
61 E/A Can Low DME/EGS module
62 E/A Can High DME/EGS module
63 E ASC throttle flap signal Accelerator pedal position sensor
64 E ASC throttle flap potentiometer (–) Accelerator pedal position sensor
65 Not used
66 A Sensor ground Left front speed sensor (ABS)
67 A Sensor ground Right front speed sensor (ABS)
68 A Sensor ground Left rear speed sensor (ABS)
69 A Sensor ground Right rear speed sensor (ABS)
70 E Pump motor signal ABS pump motor relay
71 Not used
72 E Brake pedal position Brake light switch
73 Not used
74 M Ground Ground point
75 Not used
76 Not used
77 A Left front outlet valve ABS hydraulic unit
78 A Right rear outlet valve ABS hydraulic unit
79 A Left rear inlet valve ABS hydraulic unit
80 A Left rear outlet valve ABS hydraulic unit
81 A Right front outlet valve ABS hydraulic unit
82 A Right front inlet valve ABS hydraulic unit
83 A Activate relay ABS pump motor relay
84 A Left front inlet valve ABS hydraulic unit
85 E ASC throttle flap potentiometer (+) Accelerator pedal position sensor
