3450.1bĆb
1998
Pin Assignments (318is)
04/99
BM
BMW
BMWBMW
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
86 A ABS signal ABS pump motor relay/Hydraulic unit
87 E Speed signal Left front speed sensor (ABS)
88 E Speed signal Right front speed sensor (ABS)
89 E Speed signal Left rear speed sensor (ABS)
90 E Speed signal Right rear speed sensor (ABS)
91 E/A TxD diagnostic data link Data link connector
92 A Right rear speed signal DME module
93 Not used
94 E ASC signal ASC switch
95 E Slip control system warning lamp Slip control module (ASC)
96 M Ground Ground point
97 A ASC signal Instrument cluster
X11395
Pin Type Description/Function Connection
1 A ADS step motor (+) ADS step motor
2 M Ground Ground point
3 A ADS step motor (–) ADS step motor
4 E Voltage supply Fuse 38
5 A ABS signal ABS hydraulic unit
