BMW E36 - Pin Assignments (X10182)

6100.0Ća
BMW
BMW
BMW
1998
Pin Assignments
04/99
BMW
E = Input, A = Output, M = Ground
E = X10182 18 Pins, black
F = X13252 15 Pins, black
G = X13253 26 Pins, yellow
H = X13254 26 Pins, green
I = X13255 26 Pins, nature
J = X13258 15 Pins, white
X10182
Pin Type Description/Function Connection
1 E Crash signal Crash control unit
2 E Light signal Light switch
3 Not used
4 E Voltage supply, terminal R Front power distribution box, fuse 43
5 M Ground Ground
6 Not used
7 A Activate relay Horn relay (Alpine)
8 Not used
9 A Diagnosis RxD signal Data link connector
10 Not used
11 E/A Diagnosis TxD signal Data link connector
12 E Start signal Starter
13 Not used
14 Not used
15 A Drive-away protection Electronic immobilizer control module
(EWS II)
16 Not used
17 Not used
18 E Power supply Front power distribution box
