BMW E36 - Pin Assignments (X13255)

6100.0Ćd
BMW
BMW
BMW
1998
Pin Assignments
04/99
BMW
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
11 Not used
12 Not used
13 Not used
14 E Luggage compartment lid signal Luggage compartment lid switch
15 A Data signal Relay module
16 A Data signal Relay module
17 A Data signal Relay module
18 Not used
19 Not used
20 Not used
21 Not used
22 Not used
23 Not used
24 Not used
25 Not used
26 Not used
X13255
Pin Type Description/Function Connection
1 A Data signal Relay module
2 E OPEN signal Left rear power window switch
3 E OPEN signal Right rear power window switch
4 E Convertible: OPEN signal
Four-door: OPEN signal
Main power window switch
Driver’s rear window switch
5 E Convertible: Data signal
Four-door: CLOSE signal
Convertible top control module
Passenger’s rear window switch
6 Not used
7 A Data signal Relay module
8 E CLOSE signal Left rear power window switch
9 E CLOSE signal Right rear power window switch
10 E Convertible: CLOSE signal
Four-door: CLOSE signal
Main power window switch
Driver’s window switch
