BMW E36 - Pin Assignments (X13258)

6100.0Će
BMW
BMW
BMW
1998
Pin Assignments
04/99
BMW
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionType
11 E Convertible: Data signal
Four-door: OPEN signal
Convertible top control module
Passenger’s window switch
12 Not used
13 Not used
14 Not used
15 Not used
16 Not used
17 Not used
18 Not used
19 Not used
20 Not used
21 Not used
22 Not used
23 Not used
24 Not used
25 Not used
26 Not used
X13258
Pin Type Description/Function Connection
1 E Data signal Central body electronic module
2 A Voltage supply (motor) Right rear power window motor
3 E Signal Right rear power window motor
4 E Signal Left rear power window motor
5 A Voltage supply (motor) Left rear power window motor
6 Not used
7 Not used
8 M Ground Ground
9 E Data signal Central body electronic module
10 E/A Data signal Central body electronic module
11 E/A Data signal Central body electronic module
